- 【Multiple Functions】: The OBD2 scanner is a versatile device that can fully and quickly diagnose your car's current data. It can determine why the engine light is on, read codes, clear fault codes, view freeze frames, I/M ready, vehicle information, data streams, obtain engine RPM and more.
- 【Clear Reading】: It features a clear LCD screen with white light and contrast adjustments for direct display of test results. It supports six languages, including English, German, Italian, Dutch, Spanish and French. Six buttons are freely switchable and support shortcut keys to inquire VIN (vehicle ID number) and DTC (trouble codes).
- 【Carefree Tool】: The plastic housing is tough and wear-resistant, not easy to break. The flexible cable connection is sensitive. The product can be used for a long time. In addition, with a quick diagnosis of your car, you can detect potential problems and avoid unnecessary and excessive repair costs.
- 【Easy to Use】: All you need to do is plug it into your car's ODBII port to get it connected, then the information is ready to be read. It's compact and ergonomically designed to be easily grasped with one hand, so it won't take up much space in your trunk or toolbox when not in use.
- 【Compatible Range】: Automotive OBD2 scan reader has a 16-pin standard interface. It supports up to 9 protocols, which you can view on the details page. It is suitable for most cars after 1996 (US), 1998 (Canada), 2002 (EU) and 2008 (Asia). Please check the compatibility before placing your order.
Specification:
Material: Plastic
Quantity: 1 PC
Model: V310
Color: Black & Yellow
Weight: 0.63 lb
Size: 6.1×2.87×0.97 inches
Working Voltage: DC 9-16 V
Working Current: 80 mA
Feature: Versatile, Practical, Precise
Fit Type: Universal Fit
This product can perform the following operations:
-Read error diagnostic codes (both generic and manufacturer-specific) and display their meaning (the database has over 3000 generic code definitions).
-Read vehicle error codes.
-Clears the error codes and switches off the MIL ("check engine" light).
-View freeze frame.
-I/M ready.
-Obtain vehicle information.
-Data streaming.
-Real-time curves.
-Get vehicle speed information.
-Calculate load value.
-Engine coolant temperature.
-Get engine tachometer.
-One-key query for frame number.
-Fault code one-key query.
This scanner supports the following protocols:
-SAE J1850 VPW (10.4 kbaud)
-SAE J1850 PWM (41.6 kbaud)
-ISO 9141-2 (5 baud init, 10.4 kbaud)
-ISO 14230-4 KWP (5 baud init, 10.4 kbaud)
-ISO 14230-4 KWP (fast init, 10.4 kbaud)
-ISO 15765-4 CAN (11 bit ID, 500 kbaud)
-ISO 15765-4 CAN (29 bit ID, 500 kbaud)
-ISO 15765-4 CAN (11 bit ID, 250 kbaud)
-ISO 15765-4 CAN (29 bit ID, 250 kbaud)
